Types of Firewalls

Types of Firewalls

There are three basic types of firewalls, and we’ll consider each of them.

Application Gateways

The first firewalls were application gateways, and are sometimes known as proxy gateways. These are made up of bastion hosts that run special software to act as a proxy server. This software runs at the Application Layer of our old friend the ISO/OSI Reference Model, hence the name. Clients behind the firewall must be proxitized (that is, must know how to use the proxy, and be configured to do so) in order to use Internet services. Traditionally, these have been the most secure, because they don’t allow anything to pass by default, but need to have the programs written and turned on in order to begin passing traffic.

Figure 5: A sample application gateway
\begin{figure}
\begin{center}\setlength {\unitlength}{0.00041700in}\begingr...
...{375}}
\put(2926,-961){\vector( 0, 1){675}}\end{picture}\end{center}\end{figure}



These are also typically the slowest, because more processes need to be started in order to have a request serviced. Figure 5 shows a application gateway.

Packet Filtering

Packet filtering is a technique whereby routers have ACLs (Access Control Lists) turned on. By default, a router will pass all traffic sent it, and will do so without any sort of restrictions. Employing ACLs is a method for enforcing your security policy with regard to what sorts of access you allow the outside world to have to your internal network, and vice versa.

There is less overhead in packet filtering than with an application gateway, because the feature of access control is performed at a lower ISO/OSI layer (typically, the transport or session layer). Due to the lower overhead and the fact that packet filtering is done with routers, which are specialized computers optimized for tasks related to networking, a packet filtering gateway is often much faster than its application layer cousins. Figure 6 shows a packet filtering gateway.

Because we’re working at a lower level, supporting new applications either comes automatically, or is a simple matter of allowing a specific packet type to pass through the gateway. (Not that the possibility of something automatically makes it a good idea; opening things up this way might very well compromise your level of security below what your policy allows.)

There are problems with this method, though. Remember, TCP/IP has absolutely no means of guaranteeing that the source address is really what it claims to be. As a result, we have to use layers of packet filters in order to localize the traffic. We can’t get all the way down to the actual host, but with two layers of packet filters, we can differentiate between a packet that came from the Internet and one that came from our internal network. We can identify which network the packet came from with certainty, but we can’t get more specific than that.

Hybrid Systems

In an attempt to marry the security of the application layer gateways with the flexibility and speed of packet filtering, some vendors have created systems that use the principles of both.

Figure 6: A sample packet filtering gateway
\begin{figure}
\begin{center}\setlength {\unitlength}{0.00041700in}\begingr...
...{525}}
\put(2926,-961){\vector( 0, 1){675}}\end{picture}\end{center}\end{figure}



In some of these systems, new connections must be authenticated and approved at the application layer. Once this has been done, the remainder of the connection is passed down to the session layer, where packet filters watch the connection to ensure that only packets that are part of an ongoing (already authenticated and approved) conversation are being passed.

Other possibilities include using both packet filtering and application layer proxies. The benefits here include providing a measure of protection against your machines that provide services to the Internet (such as a public web server), as well as provide the security of an application layer gateway to the internal network. Additionally, using this method, an attacker, in order to get to services on the internal network, will have to break through the access router, the bastion host, and the choke router.

So, what’s best for me?

Lots of options are available, and it makes sense to spend some time with an expert, either in-house, or an experienced consultant who can take the time to understand your organization’s security policy, and can design and build a firewall architecture that best implements that policy. Other issues like services required, convenience, and scalability might factor in to the final design.

Some Words of Caution

The business of building firewalls is in the process of becoming a commodity market. Along with commodity markets come lots of folks who are looking for a way to make a buck without necessarily knowing what they’re doing. Additionally, vendors compete with each other to try and claim the greatest security, the easiest to administer, and the least visible to end users. In order to try to quantify the potential security of firewalls, some organizations have taken to firewall certifications. The certification of a firewall means nothing more than the fact that it can be configured in such a way that it can pass a series of tests. Similarly, claims about meeting or exceeding U.S. Department of Defense “Orange Book” standards, C-2, B-1, and such all simply mean that an organization was able to configure a machine to pass a series of tests. This doesn’t mean that it was loaded with the vendor’s software at the time, or that the machine was even usable. In fact, one vendor has been claiming their operating system is “C-2 Certified” didn’t make mention of the fact that their operating system only passed the C-2 tests without being connected to any sort of network devices.

Such gauges as market share, certification, and the like are no guarantees of security or quality. Taking a little bit of time to talk to some knowledgeable folks can go a long way in providing you a comfortable level of security between your private network and the big, bad Internet.

Additionally, it’s important to note that many consultants these days have become much less the advocate of their clients, and more of an extension of the vendor. Ask any consultants you talk to about their vendor affiliations, certifications, and whatnot. Ask what difference it makes to them whether you choose one product over another, and vice versa. And then ask yourself if a consultant who is certified in technology XYZ is going to provide you with competing technology ABC, even if ABC best fits your needs.
